Round Wire Data

This page has data on the weight per metre of round wire. This can assist you in calculating the weight of a cut piece of wire before you order it.

Jump to the alloy tables below:
Sterling Round Wire
Fine Silver Round Wire
Gold Round Wire
Platinum and Palladium Round Wire



Sterling Silver Round Wire



	Weight per metre (grams)
Wire Size (mm)	Sterling
0.50	2.0
0.60	2.9
0.70	4.0
0.80	5.2
0.90	6.6
1.00	8.2
1.10	9.9
1.20	11.8
1.30	13.8
1.40	16.0
1.50	18.4
1.60	20.9
1.70	23.6
1.80	26.5
1.90	29.5
2.00	32.7
2.10	36.0
2.20	39.5
2.30	43.2
2.40	47.0
2.50	51.1
2.60	55.2
2.70	59.5
2.80	64.0
2.90	68.7
3.00	73.5
3.10	78.5
3.20	83.6
3.30	89.0
3.40	94.4
3.50	100.1
3.60	105.9
3.70	111.8
3.80	117.9
3.90	124.2
4.00	130.7
4.10	137.3
4.20	144.1
4.30	151.0
4.40	158.1
4.50	165.4
4.60	172.8
4.70	180.4
4.80	188.2
4.90	196.1
5.00	204.2
5.50	247.1
6.00	294.1
6.50	345.1
7.00	400.2
7.50	459.5
8.00	522.8
8.50	590.1
9.00	661.6
9.50	737.2
10.00	816.8



Fine Silver Round Wire



	Weight per metre (grams)
Wire Size (mm)	Fine Silver
0.5	2.1
0.6	3.0
0.7	4.0
0.8	5.3
0.9	6.7
1.0	8.2
1.1	10.0
1.2	11.9
1.3	13.9
1.4	16.1
1.5	18.5
1.6	21.1
1.7	23.8
1.8	26.7
1.9	29.7
2.0	33.0
2.1	36.3
2.2	39.9
2.3	43.6
2.4	47.5
2.5	51.5
2.6	55.7
2.7	60.1
2.8	64.6
2.9	69.3
3.0	74.1
3.1	79.2
3.2	84.4
3.3	89.7
3.4	95.2
3.5	100.9
3.6	106.8
3.7	112.8
3.8	119.0
3.9	125.3
4.0	131.8
4.1	138.5
4.2	145.3
4.3	152.3
4.4	159.5
4.5	166.8
4.6	174.3
4.7	182.0
4.8	189.8
4.9	197.8
5.0	206.0
5.5	249.2
6.0	296.6
6.5	348.1
7.0	403.7
7.5	463.4
8.0	527.3
8.5	595.3
9.0	667.3
9.5	743.6
10.0	823.9



Gold Round Wire

	Weight per metre (grams)
Wire Size (mm)	9ct Yellow	18ct Yellow
0.50	2.2	3.0
0.60	3.2	4.4
0.70	4.3	6.0
0.80	5.6	7.8
0.90	7.1	9.9
1.00	8.8	12.2
1.10	10.6	14.7
1.20	12.7	17.5
1.30	14.9	20.6
1.40	17.2	23.9
1.50	19.8	27.4
1.60	22.5	31.2
1.70	25.4	35.2
1.80	28.5	39.4
1.90	31.8	43.9
2.00	35.2	48.7
2.10	38.8	53.7
2.20	42.6	58.9
2.30	46.5	64.4
2.40	50.7	70.1
2.50	55.0	76.1
2.60	59.5	82.3
2.70	64.1	88.7
2.80	69.0	95.4
2.90	74.0	102.4
3.00	79.2	109.6
3.10	84.5	117.0
3.20	90.1	124.7
3.30	95.8	132.6
3.40	101.7	140.7
3.50	107.8	149.1
3.60	114.0	157.8
3.70	120.4	166.7
3.80	127.0	175.8
3.90	133.8	185.2
4.00	140.7	194.8
4.10	147.9	204.6
4.20	155.2	214.7
4.30	162.6	225.1
4.40	170.3	235.7
4.50	178.1	246.5
4.60	186.1	257.6
4.70	194.3	268.9
4.80	202.7	280.5
4.90	211.2	292.3
5.00	219.9	304.3
5.50	266.1	368.3
6.00	316.7	438.3
6.50	371.7	514.3
7.00	431.0	596.5
7.50	494.8	684.8
8.00	563.0	779.1
8.50	635.5	879.5
9.00	712.5	986.1
9.50	793.9	1098.7
10.00	879.6	1217.4



Platinum and Palladium Round Wire

	Weight per metre (grams)
Wire Size (mm)	Platinum	Palladium
0.5	4.04	2.32
0.6	5.82	3.34
0.7	7.93	4.54
0.8	10.35	5.93
0.9	13.11	7.51
1.0	16.18	9.27
1.1	19.58	11.21
1.2	23.30	13.35
1.3	27.34	15.66
1.4	31.71	18.16
1.5	36.40	20.85
1.6	41.42	23.73
1.7	46.76	26.78
1.8	52.42	30.03
1.9	58.41	33.46
2.0	64.72	37.07
2.1	71.35	40.87
2.2	78.31	44.86
2.3	85.59	49.03
2.4	93.19	53.38
2.5	101.12	57.92
2.6	109.37	62.65
2.7	117.95	67.56
2.8	126.84	72.66
2.9	136.07	77.94
3.0	145.61	83.41
3.1	155.48	89.06
3.2	165.68	94.90
3.3	176.19	100.93
3.4	187.03	107.13
3.5	198.20	113.53
3.6	209.68	120.11
3.7	221.49	126.87
3.8	233.63	133.83
3.9	246.09	140.96
4.0	258.87	148.28
4.1	271.97	155.79
4.2	285.40	163.48
4.3	299.15	171.36
4.4	313.23	179.42
4.5	327.63	187.67
4.6	342.35	196.10
4.7	357.40	204.72
4.8	372.77	213.53
4.9	388.46	222.52
5.0	404.48	231.69
5.5	489.42	280.35
6.0	582.45	333.64
6.5	683.57	391.56
7.0	792.78	454.12
7.5	910.08	521.31
8.0	1035.47	593.13
8.5	1168.95	669.59
9.0	1310.52	750.68
9.5	1460.17	836.41
10.0	1617.92	926.77



To Order

Please open the Fabricated Metal Catalogue to see ordering options

If you are manually ordering please state the following:

• Wire Alloy
• Wire Diameter (in mm)
• Required Length (in mm)
• Any additional services such has Hard or Coiled on a per item basis.
