Platinum and Palladium Round Wire
| Wire Size (mm) | Weight per metre (grams) | |
|---|---|---|
| Platinum | Palladium | |
| 0.5 | 4.04 | 2.32 |
| 0.6 | 5.82 | 3.34 |
| 0.7 | 7.93 | 4.54 |
| 0.8 | 10.35 | 5.93 |
| 0.9 | 13.11 | 7.51 |
| 1.0 | 16.18 | 9.27 |
| 1.1 | 19.58 | 11.21 |
| 1.2 | 23.30 | 13.35 |
| 1.3 | 27.34 | 15.66 |
| 1.4 | 31.71 | 18.16 |
| 1.5 | 36.40 | 20.85 |
| 1.6 | 41.42 | 23.73 |
| 1.7 | 46.76 | 26.78 |
| 1.8 | 52.42 | 30.03 |
| 1.9 | 58.41 | 33.46 |
| 2.0 | 64.72 | 37.07 |
| 2.1 | 71.35 | 40.87 |
| 2.2 | 78.31 | 44.86 |
| 2.3 | 85.59 | 49.03 |
| 2.4 | 93.19 | 53.38 |
| 2.5 | 101.12 | 57.92 |
| 2.6 | 109.37 | 62.65 |
| 2.7 | 117.95 | 67.56 |
| 2.8 | 126.84 | 72.66 |
| 2.9 | 136.07 | 77.94 |
| 3.0 | 145.61 | 83.41 |
| 3.1 | 155.48 | 89.06 |
| 3.2 | 165.68 | 94.90 |
| 3.3 | 176.19 | 100.93 |
| 3.4 | 187.03 | 107.13 |
| 3.5 | 198.20 | 113.53 |
| 3.6 | 209.68 | 120.11 |
| 3.7 | 221.49 | 126.87 |
| 3.8 | 233.63 | 133.83 |
| 3.9 | 246.09 | 140.96 |
| 4.0 | 258.87 | 148.28 |
| 4.1 | 271.97 | 155.79 |
| 4.2 | 285.40 | 163.48 |
| 4.3 | 299.15 | 171.36 |
| 4.4 | 313.23 | 179.42 |
| 4.5 | 327.63 | 187.67 |
| 4.6 | 342.35 | 196.10 |
| 4.7 | 357.40 | 204.72 |
| 4.8 | 372.77 | 213.53 |
| 4.9 | 388.46 | 222.52 |
| 5.0 | 404.48 | 231.69 |
| 5.5 | 489.42 | 280.35 |
| 6.0 | 582.45 | 333.64 |
| 6.5 | 683.57 | 391.56 |
| 7.0 | 792.78 | 454.12 |
| 7.5 | 910.08 | 521.31 |
| 8.0 | 1035.47 | 593.13 |
| 8.5 | 1168.95 | 669.59 |
| 9.0 | 1310.52 | 750.68 |
| 9.5 | 1460.17 | 836.41 |
| 10.0 | 1617.92 | 926.77 |
To Order
While we develop the online estimation and ordering system, please continue to use the Other Requirements field on checkout to put the solder that you wish to order.
